ATHENS TCS122/96-R

Weather resistant for outdoor use to IP54, the 2,400 Watt TCS122/96-R arrayable two-way 12″ loudspeaker system is ideally suited for a wide range of speech and music sound reinforcement applications. The TCS122/96-R is designed to work in conjunction with Turbosound loudspeaker management systems, providing optimal FOH performance, as well as offering considerable flexibility to readily adapt to varying venue requirements.

The TCS122/96-R features a glass fibre loaded 12″ low frequency driver with an aluminium voice coil for improved transient response. The titanium dome 1.4″ neodymium motor compression driver is mounted on a rotatable 90° horizontal by 60° vertical proprietary Dendritic waveguide, which features multiple hornlets with identical path lengths to provide a flat constant-phase wavefront. When the waveguide is rotated 90° from the standard position a 60° horizontal by 90° vertical dispersion is achieved, making the TCS122/96-R ideal for an even broader range of applications.

Finished in a highly durable weather resistant semi matt black paint, the trapezoidal cabinet is constructed from 15 mm (5⁄8″) birch plywood – and includes a rugged outdoor powder coated perforated zinc plated steel mesh grille. Multiple rigging points allow bracket mount suspension in any orientation, or mounting with dedicated brackets – available separately. A dedicated range of fly plates and coupler kits are also available separately for constructing tightly packed custom full-range and subwoofer enclosure arrays for aesthetically pleasing and venue specific coverage requirements. Connectivity is provided in the form of a captive cable tail, which enters the cabinet by means of a sealed cable gland on an aluminium panel.

• Arrayable 2 way full range loudspeaker for installation applications
• Rotatable Dendritic waveguide with 90? H x 60? V dispersion
• 600 Watts continuous, 2,400 Watts peak power
• All components weather resistant to IP54 for outdoor use
• Glass fibre loaded 12″ low frequency driver with aluminium voice coil for improved transient response
• Titanium dome 1.4″ neodymium motor compression driver
• Multiple array configurations for extended coverage
• Switchable passive/bi-amp operation for flexibility of use
• Trapezoidal cabinet shape enables visually unobtrusive loudspeaker arrays
• Multiple internal rigging points allow bracket mount and suspension in any orientation
• 15 mm (5/8″) birch plywood enclosure with hard wearing semi matt black paint finish
• Architecturally styled powder coated perforated plated steel mesh grille with foam backing
• Captive cable tail with sealed cable gland on aluminium connector panel
• 10-Year Warranty Program*
• Designed and engineered in the U.K.
