ATHENS TCS152/64

The 2 way full range TCS152/64 is a switchable passive/bi-amp 15″ 2,400 Watt arrayable loudspeaker system that is ideally suited for a wide range of speech and music sound reinforcement applications. The TCS152/64 is designed to work in conjunction with Turbosound loudspeaker management systems, providing optimal FOH performance, as well as offering considerable flexibility to readily adapt to varying venue requirements.

The TCS152/64 arrayable loudspeaker features a carbon fibre loaded 15″ low frequency driver with inside/outside wound coil with low mass voice coil for improved transient response, and a titanium dome 1.4″ neodymium motor compression driver mounted on a rotatable 60° horizontal by 40° vertical Dendritic waveguide. All drivers are matched with an internal passive crossover network in a reflex-loaded enclosure, and bi-amp mode can be enabled by means of a rear panel switch. The rear panel connector plate carries Neutrik speakON* NL4 and barrier strip connectors for input and link connections to additional enclosures.

Turbosound’s proprietary HF Dendritic waveguide features multiple hornlets with identical path lengths, which are engineered to provide a flat constant-phase wavefront with a 60° horizontal by 40° vertical dispersion pattern. When the waveguide is rotated 90° from the standard position, a 40° horizontal by 60° vertical dispersion is achieved, making the TCS152/64 ideal for an even broader range of applications.

Finished in a highly durable semi matt black paint, the cabinet is constructed from 15 mm (5⁄8″) birch plywood – and includes a rugged powder coated perforated steel mesh grille backed with reticulated foam. Internal M10 threaded rigging points are provided for suspension in any orientation, or mounting with dedicated brackets – available separately. A dedicated range of fly plates and coupler kits are also available separately for constructing tightly packed custom full-range and subwoofer enclosure arrays for aesthetically pleasing and venue specific coverage requirements.

• Arrayable 2 way full range loudspeaker for installation applications
• Rotatable Dendritic waveguide with 60? H x 40? V dispersion
• 600 Watts continuous, 2,400 Watts peak power
• Carbon fibre loaded 15″ low frequency driver with inside/outside wound coil
• Titanium dome 1.4″ neodymium motor compression driver
• Multiple array configurations for extended coverage
• Switchable passive/bi-amp operation for flexibility of use
• Trapezoidal cabinet shape enables visually unobtrusive loudspeaker arrays
• Multiple internal rigging points allow bracket mount and suspension in any orientation
• 15 mm (5/8″) birch plywood enclosure with hard wearing semi matt black paint finish
• Architecturally styled powder coated perforated steel mesh grille
• Neutrik speakON* NL4 and barrier strip connectors
• 10-Year Warranty Program*
• Designed and engineered in the U.K.
