• 1000W system power paired with custom transducers deliver gig-level volumes with room to spare

12′ high-output LF driver/ 1-4′ titanium dome compression driver

• High-Definition Audio Processing for professional sound with unmatched clarity

Patented acoustic correction developed with touring geniuses at EAW®

Precision 2-way crossover

Driver time alignment and phase correction

• Quick one-button Speaker Mode selection for application-specific voicing (PA, DJ, Monitor and Soloist)

• Effortlessly eliminate nasty feedback with one-button automatic Feedback Destroyer

• Integrated 2-channel mixer featuring dual Mackie Vlfide-ZTM inputs

Handles anything from mics to guitars to mixers with a single twist of the gain knob

Includes stereo RCA inputs for easy connection to music source

Perfect for the singer/songwriter, plug in and leave the mixer at home

• Smart ProtectTM DSP kicks in to protect your investment when things get pushed a little too hard

• Monitor-specific angle and voicing mode perfect for cutting through on stage

• Flyable for permanent install, both vertically and horizontally

• Proven highly-durable, portable design



  Acoustic Performance

  • Frequency Response (—3 dB) 55 Hz – 20 kHz [SRM350V3]

  47 Hz – 20 kHz [SRM450V3]

  •  Frequency Response (-10 dB) 50 Hz – 23 kHz [SRM35OV3]

  42 Hz – 23 kHz [SRM450V3]

  • Max peak SPL 126 dB [SRM350V3]

  128 dB [SRM450v3]

  • Crossover Point 3 kHz
  • Disperslon (H x V) 90‘ x 80′ [SRM350V3] 90′ x 45‘ [SRM450v3]

  High-Pregnancy Section

  • Compression Driver 1.4 In / 36 mm
  • Diaphragm Material Tltanlum
  • Magnet Material Ferrite

  Low-Frequency Section

  • Woofer Diameter 10.0 In / 254 mm [SRMSSOVS]

  12.0 In I 305 mm [SRM450V3]

  • Cone Material Paper
  • Magnet Material Ferrite

  Power Amplifiers

  • System Power Amplification
  • Rated Power 500 watts nns
  • 1000 watts peak

  Low Frequency Power Amplifier

  • Rated Power 400 watts ms

  800 watts peak

  • Rated THD < 1 %
  • Cooling Convection
  • Design Class D

  lnput/Output

  • Channel 1

  Mic-Line 8 Ohm balanced

  1/4” TRS, Wide-Z” 1 M Ohm unbalanced

  • Channel 2

  Mlc-Llne 8 Ohm balanced

  1/4″ TRS, Wide-Z” 1 Ohm unbalanced

  RCA 25 Ohm unbalanced

  • Thru

  [Passive when the Ch 1 / Mix switch is in the “out” (Ch 1) position] [Active when the Ch 1 / Mix switch is in the “in” (Mix) position]

  Power

  US detachable line cord 100 – 120 VAC. 50 – 60 Hz, 160W

  EU detachable line cord 220 – 240 VAC, 50 – 60 Hz, 160W

  AC Connector 3-pln IEC 250 VAC, 10 A male

  Power Supply Type Switchmode

  Operating Temperature 0 – 40 ‘0

  [extended ambient temperature] 82 – 104 ‘F

  Safety Features

  • Input Protection Peak and RMS limiting. power supply and amplilier thermal protection
  • Display LEDs Defeatable lront power, input signal/0L, speaker mode,feedback destroyer on/ofl and active filters, system limiter

  Construction Features

  • Cabinet Polypropylene
  • Finish Black. textured finish
  • Gnille Perforated metal with weather-resistant coating
  • Fly Points Three M10 x 1.5 x 20 mm [SRM450V3]
  • Monitor Angie 50′ [SRM350V3] 40′ [SRM450V3]

  Mounting Methods

  • SRM350v3: Floor mount, pole mount or fly via optional bracket.
  • SRM450V3: Floor mount, pole mount or fly via three integrated M10 mounting points (using M10 x 1.5 x 20 mm forged shoulder eyebolts).

  Physicai Properties (packaged product)

  • SRM35OV3

  Height 25.0 in / 635 mm

  Width 15.2 in / 386 mm

  Depth 13.2 in / 335 mm

  Weight 29 lb / 13.2 kg

  • SRM450V3

  Height 29.0 in / 737 mm

  Width 17.5 in / 445 mm

  Depth 17.0 in / 432 mm

  Weight 43 lb / 19.5 kg

  Physicai Properties (product)

  • SRM350V3

  Height 20.8 in l 527 mm

  Width 13.1 in / 333 mm

  Depth 1 2.3 in / 311 mm

  Weight 23 lb / 10.4 kg

  • SRM450v3

  Height 26.1 in / 663 mm

  Width 16.0 in / 406 mm

  Depth 14.8 in / 376 mm

  Weight 37 lb / 16.8 kg

  Options

  • SRM350v3 Loudspeaker Bag P/N 093-024-00
  • SRM450v3 Loudspeaker Bag P/N 0002843
  • SPM200 Loudspeaker Pole Mount P/N 2035170-01

  (3 x M10 x1.5 x 20 mm) P/N 0031943

  • SRM350v3 Bracket Kit P/N 0016404

  Ordering Information

  SRM350v3 1000W Powered Loudspeaker, US P/N 2042789-00

  SRM350v3 1000W Powered Loudspeaker, EU P/N 2042789-01

  SRM350v3 1000W Powered Loudspeaker, UK P/N 2042789-03

  SRM350v3 1000W Powered Loudspeaker, AU P/N 2042789-04

  SRM350v3 1000W Powered Loudspeaker, CN P/N 2042789-05

  SRM350v3 1000W Powered Loudspeaker, BZ (120V) P/N 2042789-06

  SRM350v3 1000W Powered Loudspeaker, BZ (230V) P/N 2042789-16

  SRM450v3 1000W Powered Loudspeaker, US P/N 2042790-00

  SRM450v3 1000W Powered Loudspeaker, EU P/N 2042790-01

  SRM450v3 1000W Powered Loudspeaker, UK P/N 2042790-03

  SRM450v3 1000W Powered Loudspeaker, AU P/N 2042790-04

  SRM450v3 1000W Powered Loudspeaker, CN P/N 2042790-05

  SRM450v3 1000W Powered Loudspeaker, BZ (120V) P/N 2042790-06

  SRM450v3 1000W Powered Loudspeaker, BZ (230V) P/N 2042790-16
