CERWIN-VEGA P1500X
Powered Loudspeaker 15″ Two-Way 1500W Class D

The P1500X is a two-way, bi-amped, full-range bass-reflex speaker. It employs a 15-inch woofer and a high-frequency compression driver, powered by a custom Class-D amplifier.

With a power rating of 1500 watts, the P1500X is the most powerful PA product in its class. A proprietary hemi-conical horn provides premium sound clarity over an even and wide coverage area.

A built-in mixer with convenient I/O connections allows for simple and fast setup, while Enhanced EQ, VEGA BASS boost and High-Pass Filters enable exact tuning and exceptional performance for any application.

The P1500X is a versatile product that can be used as a single speaker for a small venue, set in pairs or installed with threaded hang points for a larger venue needing more coverage and SPL, or as a floor monitor for a band.

• Fully integrated sound reinforcement system results in a simplified solution to delivering public address, entertainment and performance monitoring

• Rugged enclosure with multiple handle locations makes transport and setup safe and easy

• Full-range and subwoofer models use high efficiency Cerwin-Vega! components for low-frequency bass with punch

• The integrated mixer and efficient amplifier design reduces the amount of gear required for an easier setup and less worry about limited powerresources

• Angle-adjustable pole mount socket, side-wedge shaped enclosure and M10-threaded suspension points support a variety of permanent andportable setups

• Stackable design to minimize transportation and storage area. Thick, powdered coated grill protects the drivers during transportation and storage

• Caster are included with the P1800SX subwoofer for easy transfer to and from theperformance area

  SPEC :

  Model: P1500X

  •

  System Configuration: Active 2-way full-range, bass reflex

  •

  Frequency Range (-10 dB): 49.8 Hz – 23.5 kHz

  •

  Frequency Response (±3 dB): 55.0 Hz – 20.5 kHz

  •

  Nomiinal Coverage (-6 dB): 90° Horizontal, 65° Vertical

  •

  Maximum SPL(1W @ 1m): 134 dB

  •

  Amplifiier Type:  Class D

  •

  Amplifier Rating: 1500 Watts Dynamic, 540 Watts Continuous

  •

  Low Frequency Driver: 15″

  •

  High Frequency Driver: 1¾” diaphragm, 1” exit

  •

  Connectors:  CH 1&2 – Neutrik™ XLR/TRS inputs, CH3 Dual ¼” TS THRU 1&2 – XLR, MIX XLR

  •

  Indicators:  Signal/Clip, Power, Limiter, Protect

  •

  Enclosure: Polymer cabinet, flush waveguide

  •

  Grille: 18 gauge, perforated steel

  •

  Mounting  & Suspension: 7.5 degrees down or flat, 35mm pole socket 4 x M10 suspension, 2 x M10 pull-back

  •

  Operating Temperature: -20° to 55°C
