COMICA CVM-WM200 COMBO SET
UHF(794MHz~806MHz) 80-channels Metal Wireless Microphone with Two transmitters and One Receiver (AA Battery Version)

WM200 is an all-metal wireless microphone with dual-transmitter triggered by one receiver, with two AA batteries, it utilizes UHF wireless FM technology and LCD high-resolution lattice screen, 80 channels in  total, 16-level adjustable volume, and integrated into LCF(Low cut filter) ,  Auto-scanning, Auto IR Channel-match, stereo / mono switchable audio mode, RF signal strength adjustment, MIC/LINE IN input dual selection, power monitoring at receiver end, sound pickup dynamic display, backlight adjustment and other functions, at the same time with strong shielding  anti-noise performance, it’s a high-quality microphone to broadcasting level.

Features :

• UHF 794~806 MHz frequency range.(Band for Thailand Regulation)
• Dual Transmitters Triggered by One Receiver, A/B Double Group Options
• 80 Channels, Used for Multiple Devices Working Together
• Working Distance is Up to 120m (in open area, up to 80m in Barrier Area)
• LCF Low Cut Filtering Mode
• Auto-scanning for Quick Channel Selection
• Manual or Auto IR Sync
• Adjustable RF Signal Strength
• Audio Dynamic Display Bar
• 16 Levels Volume Adjustment
• Transmitter Power Monitor
• Mono/Stereo Switchable Output Modes
• Low-consumption, Super-long Standby Time
• Lattice LCD Display, High Resolution.
• Full Metal Manufacturing, Excellent Shielding

Spec :
WM200/300-HTX (เครื่องส่งสัญญาณแบบไมค์ลอย)

Channels	80
Group A Wireless Frequency	794MHz ~806MHz
Group B Wireless Frequency	794MHz ~806MHz
Signal / Noise	>65dB
Antenna	PCB Antenna
Transmitting Power	10dbm/15dbm
Stray Radiation	<-60dBc
Sound Delay	<20ms
Audio Distortion	<0.5%
Battery	AA Batteries x 2pcs
Dimension	Φ53.5(MAX) x 253mm
Operating Temperature	0℃ ~ 50℃
Storage Temperature	-20℃~ 60℃

WM200-TX (เครื่องส่งสัญญาณ + ไมค์คลิป)

Channels	80
Group A Wireless Frequency	794MHz ~ 806MHz
Group B Wireless Frequency	794MHz ~ 806MHz
Signal / Noise	>65dB
Antenna	1/4 Wavelength Wire Antenna
Receiving Power	-95dBm
Stray Radiation	<-60dBc
Sound Delay	<20ms
Audio Distortion	<0.5%
Battery	AA Batteries x 2pcs
Dimension	84 x 63.5 x 23mm
Operating Temperature	0℃ ~ 50℃
Storage Temperature	-20℃~ 60℃

WM200-RX Receiver (เครื่องรับสัญญาณ)

Channels	80
Group A Wireless Frequency	794MHz ~ 806MHz
Group B Wireless Frequency	794MHz ~ 806MHz
Signal / Noise	>65dB
Antenna	1/4 Wavelength Wire Antenna
Receiving Power	-95dBm
Stray Radiation	<-60dBc
Sound Delay	<20ms
Audio Distortion	<0.5%
Battery	AA Batteries x 2pcs
Dimension	84 x 63.5 x 23mm
Operating Temperature	0℃ ~ 50℃
Storage Temperature	-20℃~ 60℃
