YAMAHA CL3 System ดิจิตอลมิกเซอร์ DIGITAL MIXING CONSOLE Starter Set 48Ch.
Starter Set 48Ch. (CL3 x 1, Rio3224D x 1, Rio1608 x 1, MBCL x 1 )

Mixdown 64 Mono 8 Stereo ( 48 ch. via Rio3224D + Rio3224D and 8 Omni In ) 16 DCA groups, 8 mute groups,16-fader left, 8-fader Centralogic, 2-fader master section, 16 User Defined Keys, 3 Mini-YGDAI card slots

300 Scene Memory,Effects Rack, GEQ Rack, Premium Rack , 2-track recording USB Port, 5-input/5-output GPI interface

Touch-panel Display Control, CL editor Software, Integration with Nuendo Live Software, Option: Meter bridge (MBCL)

ข้อมูลจำเพาะทั่วไป

Yamaha Rio 3224 D Digital Stagebox

This high-capacity, high-performance I/O rack is compatible with Yamaha CL and QL series consoles as well as the RIVAGE PM series. It features 32 analog inputs, 16 analog outputs, and eight digital AES/EBU outputs. The Rio3224-D2 connects directly to Dante digital audio networks, allowing flexible system configuration. Dual power supply units are built in for high reliability, and a character/graphic display offers easy visual confirmation.

• 32 analog inputs and 16 outputs, and 8 digital outputs.
• Redundant connections are supported with primary and secondary connectors. Daisy chain connections are also supported.
• Comprehensive display and local control of gain and other parameters.
• Dual power supply units are built in for high reliability.
• Power consumption: 120W
• Dimensions (WxHxD): 480 x 220 x 368mm (18.9" x 8.7" x 14.5")
• Net Weight: 13.5 kg (29.8 lbs)

Yamaha Rio 1608 D Digital Stagebox

• Rackmount 3U ขนาด 19 นิ้ว
• ความถี่การสุ่มตัวอย่างภายในที่ 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
• ความถี่ในการสุ่มตัวอย่างภายนอก:44.1 kHz: + 4.1667%, + 0.1%, -0.1%, -4.0% (± 200ppm) 48 kHz: + 4.1667%, + 0.1%, -0.1 %, -4.0% (± 200ppm) 88.2 kHz: + 4.1667%, + 0.1%, -0.1%, -4.0% (± 200ppm) 96 kHz: + 4.1667%, + 0.1%, -0.1%, -4.0%
• ช่องเสียบ Output แบบ XLR 8 ช่อง
• ช่องเสียบ Input รวม 16 ช่อง
• สามารถใช้กับซอฟแวร์ของ Dante ได้
• น้ำหนัก: 8.8 กก
