Features :

• มี input ทั้งหมด 16 input ประกอบด้วย 8 Combo-Jack, 4 XLR, 2 RCA in, 2 USB Playback
• มี Output Stereo ทั้งแบบ XLR และ Phone Jack และมี 4 Aux Output แบบ XLR
• มีช่องสำหรับเสียบ Headphone 2 ช่อง
• มีช่องสำหรับใช้งานกีตาร์ Hi- Z/instrument inputs พร้อมกับ Effects กีตาร์ ของ Digitech ใน Channel 1 และ 2
• มี Wi-Fi ติดตั้งในตัว
• มีการควบคุม Digital Mixer ผ่าน GUI (Graphical user interface) มี Web browser สามารถใช้ได้ทั้ง iOS, Android, Windows, Mac OS, and Linux devices
• สามารถควบคุมผ่าน (Tablet/PC/Smartphone) ใช้ได้ถึง 10 เครื่อง พร้อมกัน
• มีภาค ffect, Dynamic ของ bx, Digitech, Lexicon
• มี 4-band Parametric EQ, High-Pass Filter, Compressor, De-esser และ Noise Gate บน input ของ Channel
• มี 31-band Graphic EQ, Noise Gate and Compressor ของ Output ทั้งหมด
• มีฟังค์ชั่น Real-Time Frequency Analyzer (RTA) บน input และ Output
• มี 3 Effects processors: Reverb, Delay and Chorus
• มีฟังค์ชั่น Subgroups, Mute Groups, View Groups, and more mixer controls
• มีฟังค์ชั่น Advanced Feedback Suppression (AFS)
• มี USB audio playback สามารถเล่นไฟล์ MP3, WAV และ AIFF formats.
• สามารถ Recording ผ่าน USB ได้เป็น -Track
• มีช่องสำหรับเชื่อมต่อ HDMI
• มี Rack Mount สามารถนำไปยึดกับ Rack Size มาตราฐาน

     Ui16 packs a complete digital mixing system into a compact, road-rugged stagebox format, with built-in Wi-fi and the ability to be controlled by any connected device via a standard web browser - no Apps, no OS limitations, no constraints on how or where you mix.

Key Features

• Tablet/PC/Smartphone Controlled Digital Mixer
• Integrated Wi-Fi
• Cross-platform compatibility with iOS, Android, Windows, Mac OS, and Linux devices
• Use up to 10 control devices (tablets, phones, PCs) simultaneously
• Legendary Harman Signal Processing from dbx®, Digitech®, and Lexicon®
• Fully recallable and remote-controlled mic preamps
• 4-band Parametric EQ, High-Pass Filter, Compressor, De-esser and Noise Gate on input channels
• 31-band Graphic EQ, Noise Gate and Compressor on all outputs
• Real-Time Frequency Analyser (RTA) on inputs and outputs
• 3 dedicated Lexicon® FX effects processors: Reverb, Delay and Chorus
• Subgroups, Mute Groups, View Groups, and more mixer controls
• Show/Snapshot recall with channel safes and security lockout
• 2-channel USB audio playback and recording

Overview

     The Ui Series mixers feature cross-platform compatibility with iOS, Android, Windows, Mac OS, and Linux devices, and can use up to 10 control devices simultaneously. In addition, the Ui12 and Ui16 each feature built-in HARMAN signal processing from dbx, DigiTech and Lexicon, including dbx AFS2, DigiTech Amp Modeling, and more. Both models feature fully recallable and remote-controlled mic gain and phantom power, along with 4-band parametric EQ, high-pass filter, compressor, de-esser and noise gate on input channels.

    Both mixers offer 31-band graphic EQ, noise gate and compressor on all outputs, plus real-time frequency analyser (RTA) on inputs and outputs. Built in are three dedicated Lexicon FX busses: Reverb, Delay and Chorus. In addition, mixer controls include Subgroups, Mute groups and View groups, among others. The Ui Series mixers feature full Show/Snapshot recallability with channel recall safes. while security lockout features allow customization of device access to only specific functions and mixes if needed. Both mixers also offer independent network interfaces on board for simultaneous control by Wi-Fi and Ethernet, plus a floor-ready rugged chassis for live applications.

    The Ui16 boasts eight XLR combo mic/line inputs, four XLR mic inputs, two channels of Hi- Z/instrument inputs, as well as a stereo RCA line input. A 2-channel USB media player is included, along with four balanced XLR Aux outputs, two quarter-inch headphone outputs with level control, plus balanced stereo XLR and quarter-inch main outputs. Two-channel USB audio playback is compatible with MP3, WAV and AIFF formats, and 2-channel USB Record direct-to-memory devices functionality is possible as well. The Ui16 also has an HDMI display connection output.
