MIDAS M32C ดิจิตอลมิกเซอร์ Digital Rack Mixer 40-Input 8 DCA มิกเซอร์ดิจิตอล อินพุต 40 ช่อง 8 DCA and 6 mute groups 8 digital signal processing effects engines 32 x 32

Digital Rack Mixer for Installed and Live Sound Applications with 40 Input Channels and 25 Mix Buses

     The Midas M32C is a digital rack mixer that features up to 40 simultaneous input channels when used with an optional networked remote I/O solution such as the Midas DL16 digital stage box. Boasting 25 time-aligned, phase-coherent mix buses, and 8 digital FX engines, the M32C offers a flexible solution for a multitude of live sound, broadcast, and recording applications.

     The M32C is housed in an aluminum and steel chassis with a compact 1U rack-mountable form factor. Currently able to capture audio at 24-bit, 48 kHz sample resolution, the console is "future-proofed" with 96 kHz capable open architecture, which Midas intends to make available for the line.

     Including an extensive array of on-board effects, the M32C features 8 stereo, studio-grade effects engines, each assignable to any input, group or output mix bus. Choose from high-end FX modules, including a range of reverbs, delays, EQs, dynamics, and much more. Modeled after some of history's most iconic and sought-after effects processors such as the Teletronix LA-2A, the M32C's effects run inside the low-latency, 40-bit floating point environment of the mix engine.

• 40-input channel, 25-bus, 1U rackmountable digital mixing core for live and installed sound applications
• 25 time-aligned and phase-coherent mix buses
• AES50 networking allows up to 96 inputs and 96 outputs
• Open architecture allows for future 96 kHz operation
• High-performance aluminum and high-impact steel structure
• 40-bit floating point digital signal processing
• 8 DCA and 6 mute groups
• 8 digital signal processing effects engines
• 32 x 32 channel USB 2.0 audio interface
• Built-in expansion port for audio interface cards or digital networking bridges
• MIDI In/Out for remote scene recall or controlling other MIDI equipment
• DAW remote control emulations of Mackie Control and HUI protocols
• Optional wireless remote control with Midas Apps for iPhone and iPad
• Auto-ranging universal switch-mode power supply
• Designed and engineered in England

M32C

The 40-input, 25-bus M32C takes the brain of the flagship M32 Digital Mixing Console and packs it all into a high-performance aluminium and steel 1U form factor. Combine the M32C with our DL16 or DL32 Stage Boxes to effortlessly run sound with high I/O counts in multiple remote locations. Dual AES50 networking CAT5 connectors allow for up to 96 remote inputs and 48 output channels to be controlled from and processed by the M32C. All of this can be managed concurrently from various locations and instances via our free remote control software applications, M32-EDIT, M32-MIX, and M32-Q.

Above all, M32C is designed to put the power of digital in your hands, without compromise. Midas’ singular focus on a matchless value proposition means M32C integrates advanced features such as integrated personal monitor mixing and true high-speed digital audio networking as standard features.

Built for Tomorrow

The M32C is a console built for today, and tomorrow – its rock-solid proprietary operating system and the 0.8 ms audio engine provide outstanding state-of-the-art audio performance for years to come.

“Acoustic Integration” - the Live Sound Revolution

Legendary 40-year old British company Turbosound, famous for producing some of the world’s best speaker systems, have teamed up with Midas to seamlessly integrate mixer and speaker systems. We call it “Acoustic Integration”.

The M32C’s ULTRANET bus allows streaming up to 16 channels of pristine digital audio to an array of Turbosound iQ speakers – all on a single CAT5 cable, along with control data to set sound presets remotely.

Furthermore, iQ Series loudspeakers feature “True Physical Modelling” of some of the most popular speakers, which can be easily remote controlled via the M32C, allowing the sound engineer to apply different speaker models in real time from the comfort of the mixing desk.

“Acoustic Integration” is the next live sound revolution.

Specifications
