Model
Mono Input Channel

8 channels

Stereo Input Channel

2 channels(selectable.if selected, mono channels will be lessened 4 channels)

Mono Insert Channel

8 channels

Phantom Power for MIC

+48V

Output Channel

2 main output channels; 2REC output channels; 1 effects output channels; 1 monitor output channels; 1 stereophone output channel

Frequency Response

20Hz~20KHz±1dB

Mono MIC to Main Output Max Gain

50dB±3dB

Mono Line to Main Output Max Gain

30dB±3dB

Stereo Line to Main Output Max Gain

N.A.

Overhearing

<-80dB±1.5dB @1kHz

S / NR

78dB @ 0dB

Max Output Level to Main Output Channel

22dB±1.5dB

Max unbalance Group Output/Main Output Channel

16dB±1.5dB, Without Group

REC Max Unbalance Output

16dB±1.5dB

Monitor Max Unbalance Output

16dB±1.5dB

Effects Max Unbalance Output

16dB±1.5dB

Phone Output

12dB±1.5dB @ 1KHz 32Ω

Gain Inequality

≤2dB

THD

≤0.02% @ 0dB 1KHz

Mono Channel EQ

Hight Mid / Low

12KHz, 1.8KHz, 80Hz

Frequency Swing&Gain

Frequency swing<8%, Gain:±15dB

Stereo EQ

Hight Mid / Low

12KHz, 1.8KHz, 80Hz

Frequency Swing & Gain

Frequency swing<8%, Gain:±15dB

7 Main Output to GEQ

Center Frequency of EQ

63Hz, 160Hz, 400Hz, 1KHz, 2.5KHz, 6.3KHz, 16KHz

Frequency Swing & Gain

±12dB inaccuracy 2dB, Frequency swing≤8%

Effector

2 DSP of 21 different Effects: HALL, ROOM, PLATE, AMBIENT, GATED, REVERS, VOICE, DEL & REV, ECHO 40, ECHO 50, DELAY, CHORUS, CHO&DEL,
CHO & REV, FLANGER, FLA & DEL,FLA & REV, TREMOLO, TRE&REV, WAH WAH, WAH & REV

Clipping Indicator Light

Indicator 3dB earlier than cutting wave level

Group & 12 Main Outputs Levels Indicator LED

+9dB, +6dB, +3dB, 0dB, -2dB, -4dB, -6dB, -9dB, -12dB, -16dB, -18dB, -21dB

Power Supply & Power Consumption

AC 120V or 220V; 50-60Hz; <70W

Power of Amplifier

N.A.

The Dimension of External Power Supply

129x90x77mm

Product Dimension(WxDxH)

387.5×389.7×80.3mm

Net Weight

6kg

Shipping Dimension(WxDxH)

555x485x180mm/0.0485m
