ALLEN & HEATH QU-Pac Compact Mountable Mixer

The Allen & Heath Qu-Pac is a 16-in/12-out rack-mountable, console-less digital mixer that doubles as a 32×32 USB recording interface. Featuring 16 of the company’s recallable AnalogiQ microphone preamps, and powered by a 5 core ARM processor, the Qu-Pac provides a variety of integrated effects and processing, including channel-independent 4-band parametric EQs, compressors, delay, and reverb.

The mixer is compatible with both the ME Personal Mixing System and dSNAKE digital connectivity system from Allen & Heath, which allows for up to 38 inputs. The Qu-Pac can also be used with the Qu-Pad app, allowing you to use your iPad to mix from anywhere in the venue when connected to a wireless network. Engineered for intuitive navigation, the mixer also features a 5″ touchscreen display, providing access to all settings.

Features:

• 5″ Touchscreen, 16 AnalogiQ recallable preamps
• 16 On-board Mic / Line Inputs (XLR / TRS)
• Expandable up to 38 inputs via dSNAKE
• 3 Stereo Inputs (TRS), 32 Mono + 3 Stereo Input Channels
• 12 On-board Mix Outputs (XLR), 4 Stereo Groups, 2 Stereo Matrix Outs
• AES Digital Out, 4 DCA Groups, 4 Mute Groups
• Qu-Pad iPad App for all live mixing controls
• Qu-You iPhone App for personal monitoring
• Qu-Drive direct Multitrack Recording / Playback on USB drives
• 15 Soft Keys, 16 Custom Select keys
• Qu-Control custom screen to suit application
• 4 FX Engines, 4 FX Sends / Returns, 32×32 USB Audio Interface
• iLive FX Library, Compatible with ME Personal Mixing System
• Trim, polarity, HPF, gate, insert / ducker, 4-band PEQ, compressor and delay on all Inputs
• Insert, 4-band PEQ, 1/3 octave GEQ, compressor and delay on all Mix outputs
• Built-in Signal Generator, RTA with Peak Band indication

Specifications
